The YR-P27QA, a cutting-edge lighting solution designed for versatility and durability. This light boasts 27x10W 4-in-1 RGBW light sources with a high-temperature lens package, ensuring a vibrant color display with a lifespan of up to 50,000 hours. The light source is protected by a bullet-proof mirror and features a high-temperature resistant PC+PMMA lens, offering a 25-degree light angle for focused illumination.
YR-P27QA is a LED par light that with 27pcs Lamps. The color is RGBW 4 in 1. LED par light as a lighting tool of LED light source, LED lamp compared with traditional lamp, more rich color.
Controlled via DMX512+RDM, adhering to the international standard light control transmission protocol, the YR-P27QA offers 8 channels A/B for flexible operation modes, including console, manual, master-slave, voice control, and optional WIFI+ mobile APP control. The built-in effects—stroboscopic, static color mixing, and self-walking—enhance its adaptability for various lighting scenarios.
This competitive led par light operates on an AC100V-240V (50/60HZ) voltage range with a total rated power of 200W and a power factor of 0.56, making it energy-efficient. Its engineering aluminum alloy case with fine sand paint is both heat and wear-resistant, suitable for environments with temperatures below 40 degrees Celsius.
It features an LED bright red digital tube display and 4 mechanical buttons, along with power and signal interfaces equipped with PowerCon and XLR connectors. Weighing just 2.8KG, this led par is the epitome of lightweight yet robust lighting technology.
Product Parameters
Light source | Light source | 27pcs*10W (4-in-1 RGBW) | |
Lifespan | 50,000 hours | ||
Antistatic | up to 2000V HBM | ||
Light Angle | 25 degrees | ||
Control parameters | Strobe | 0-20Hz, standard stroboscopic | |
Dimming | Standard linear dimming | ||
Control signal | DMX512 | ||
Control channel | 8 channels A / 8 channels B | ||
Operation mode | console, manual, master-slave, voice control, optional WIFI+ mobile APP control | ||
Cooling mode | fin + fan for heat dissipation | ||
Color | RGBW | ||
Built-in effects | Stroboscopic + static color mixing + self-walking | ||
Working parameters | Working voltage | AC100V-240V (50/60HZ) | |
Rated total power | 200W | ||
Power factor | 0.56 | ||
Maximum operating temperature | <40 degrees | ||
Light parameters | Case material | Engineering aluminum alloy (high temperature resistance), fine sand paint (high-end wear resistance) | |
Display | LED bright red digital tube +4 mechanical buttons | ||
Handle | Limit double handle, flat anti-slip | ||
Power interface | with one input and one output powercon socket | ||
Signal interface | with an in and out XLR connector | ||
IP rate | IP20 | ||
Net weight | 2.8KG | ||
8CH A | |||
S/N | MENU | FUNCTION | |
CH1 | Total dimmer | 0-255: Total dimming linear dimming, from darkest to brightest. | |
CH2 | stroboscopic | 0-9: None, 10-255: slow to fast. | |
CH3 | Functionmodel | 0-29: invalid; 30-39: red; 40-49: green; 50-59: blue; 60-99: Red - green; 70-79: Red - blue; 80-89: green-blue; 90-99: white; 100-149: Gradual change; 150-199: pulse change; 200-229: jump; 230-255: Voice control; | |
CH4 | Function speed | 0-255: Slow to fast | |
CH5 | red | 0-255: Red linear dimming, from darkest to brightest. | |
CH6 | green | 0-255: Green linear dimming, from darkest to brightest. | |
CH7 | blue | 0-255: Blue linear dimming, from darkest to brightest. | |
CH8 | white | 0-255: White linear dimming, from darkest to brightest. | |
8CH B | |||
S/N | MENU | FUNCTION | |
CH1 | Total dimmer | 0-255: Total dimming linear dimming, from darkest to brightest. | |
CH2 | red | 0-255: Red linear dimming, from darkest to brightest. | |
CH3 | green | 0-255: Green linear dimming, from darkest to brightest. | |
CH4 | blue | 0-255: Blue linear dimming, from darkest to brightest. | |
CH5 | white | 0-255: White linear dimming, from darkest to brightest. | |
CH6 | stroboscopic | 0-9: None, 10-255: slow to fast. | |
CH7 | Function model | 0-29: Dimming; 30-39: red; 40-49: green; 50-59: blue; 60-69: red - green; 70-79: Red - blue; 80-89: green-blue; 90-99: white; 100-149: Gradual change; 150-199: pulse change; 200-229: jump; 230-255: Voice control; | |
CH8 | Function speed | 0-255: Slow to fast |
FAQ
1. How to make sure your quality?
We have very clear and strict testing procedures, and we also have advaced testing equipment. The most important thing is that we use all good quality materials and never tried low quality raw materials.
2. Can you do ODM ,OEM?
Yes ,sure.
3. Is it OK to print my logo on stage light product?
Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Advantages
1. A stage lighting enterprise that gathers research, production, marketing, and after-sales as integral whole.
2.Top ten Brand enterprises of Stage lighting in China, national intellectual property standard enterprise, Guangdong Province contract abiding enterprise, China Quality credit AAA+ enterprise, etc.
3.More then fifty kinds of goods have been granted“CE” certification.
4.Our goods are popular in Europe and America, Southeast Asia, Russia., etc., more than 60 countries and regions.
